Double Layer Multispectral Camouflage Net

TECHNICAL SPECIFICATIONS

1.       Visible Lights Stealth

       Working Band: 0.4~0.76μm

       In visual range, the camouflage nets match the nature background perfectly.

2.       Near Infrared Stealth

       Working Band: 0.76~1.20μm

       In near IR range, the camouflage nets match the nature background perfectly.

3.       Thermal Infrared Stealth

       Working Band: 3~5, 8~14μm

       Temperature of the camouflaged target can be reduced by more than 10℃when target temperature is higher than the ambient temperature of20℃

4.       Radar Stealth

       Working Band: K、X、C、S、L

       Reflection rate of radar wave measured in anechoic chamber is -30dB, attenuation of RCS     figure of the target measured in radar test range is 10dB

Physical characteristics

Ø         Adhesive force (scale) ≥ 3

Ø         Rupture resistance

l            Cloth ≥ 500N

l            Carry rope ≥ 200N

l            Connect rope ≥ 500N

l            Control rope ≥ 1000N

l            Colligate rope ≥ 50N

Ø         The rupture resistance of the rope can be customized.

Ø         Cloth specular gloss (%) ≤ 3 (60°)

Ø         Fire Retardant ≤ 10 Seconds

Ø         Unit weight (6.8M× 6.8Mper unit)

Ø                Camo layer    ≤ 200g/㎡

Ø                Thermal layer  ≤ 180g/㎡

Ø         Operating life: 2 years for field

Ø         Storage life: 10 years for standard warehouse.
