Multi-spectral net has functions of anti-visual, anti-thermal infrared , and ant-radar. The net using the 2D structure, the base fabric is woven by one time and directly printed , doesn’t need to be cut and tied. It can avoid snagging and to keep the net more durable. Multi-spectral net has the advantage of simple structure, light weight, nonsnaging, strong, easy to make and maintain.
For these years, this net has been widely using in field battles and military engineering in foreign countries. It has gradually taken place of the former camouflage net in
I. Anti-Radar
Array Antenna is used for anti-radar, which makes the Multispectral Net can directly cover on the object rather than being supported like other net does. Making the net easier to use and to deploy this technology decreases the cost and expand the camouflage net’s use
II. Anti-Thermal Infrared
A Heat insulation layer which highly reflects the thermal infrared is plated on the net, preventing the heat object from being caught. Meanwhile, Dyestuff with various reflective rate on the net’s surface enables it anti-thermal infrared.
III. Features
A. Visual: Digital camouflage pattern with 3-4 colors, brightness difference from the background ≤ 0.2
B. Anti-Radar: Protective waveband Ka, Ku, C, S reduce ≥ 10dB
C. Anti-Thermal Infrared: Protective waveband: 3~5μm,8~14μm reduce ≥ 70%
D. Physical Characteristics
1. Rupture Resistance of the side rope: ≥ 1500N
2. Burst strength of the net: ≥ 350N
3. Color fastness to rub ≥ 2
4. Anti-bacteria ≤ 1
5. Anti-fog ≤ 2
6. Anti-hot ≤ 2
7. Size：6.8×6.8㎡
8. Weight ≤ 200g/㎡
9. Temperature：-40~75℃
10. Wind Loads ≥ 6
11. Live time more than 10 years in the standard storage
E. Reliability：fast assemble and disassemble, more than 1 year live time in battle field
1 Multispectral Net 2 Multispectral Net in battle field
3 Thermal-infrared image
